Features

1. Advanced MPPT Technology

  • True MPPT with the latest algorithm (tracking efficiency >99.5%)
  • Multi-peak Detection for optimal tracking in shaded conditions
  • High charge conversion efficiency (up to 98%)

2. Intelligent System Compatibility

  • Auto-detects 12V/24V systems – seamless integration
  • Supports 8+1 battery types: Lead-Acid (Gel, AGM, Wet, Crystal, Calcium) and Lithium (LiFePO₄, LTO, LCO)
  • Optional battery temp sensor for precision charging

3. Advanced Protection System

  • Triple safety protection: Over-voltage/Reverse discharge/Short-circuit
  • Weatherproof construction: IP43-rated internal components, IP22-protected connection ports
  • Lithium Battery Activation: Recovery for Lithium Batteries

4. Precision Charging Control

  • Customizable charge parameters
  • Performance data recording
  • Proprietary battery optimization algorithms

5. Intelligent Monitoring System

  • LCD shows: Real-time solar input, Battery health metrics, Custom parameter settings
  • Visual LED status bar for instant diagnostics
  • Included & Optional: Built-in bluetooth module; Optional external digital remote display

Specifications

  • System Nominal Voltage: 12/24V Auto
  • Max. PV Open Circuit Voltage: 100V DC
  • Charging Technology: MPPT
  • Max PV Charging Current: 30A
  • Charge Conversion Efficiency: ≤98%
  • MPPT Tracking Efficiency: >99.5%
  • Max. Recommended PV Input Power: 500W (12V) / 1000W (24V)
  • Battery Type Preset: Crystal, Gel, AGM, WET, Calcium / LCO, LFP, LTO
  • Housing Case Color: Black / Grey
  • Protection Rating: IP43 for Inside PCBA, IP22 for Connection Area
  • Net Weight: 0.8kg / 1.76lb
  • Dimensions (L*W*H): 180*140*73mm / 7.0*5.5*2.9in
