Features

  • True MPPT
  • Tracking Efficiency Above 99.5%
  • Charge Conversion Efficiency as High as 98%
  • 12V / 24V DC System Self-Adaptation
  • Reverse Discharge Protection
  • Targeted for Accuracy
  • Overvoltage Protection
  • Common Negative Connection
  • Charging Data Storage
  • Conformal Coating for Inside Board
  • In-house Design and Manufacture
  • Extensive Internal Electronics, In-Circuit Protections, and Safety Protections
  • Targeted for Lead Acid Batteries: Gel, AGM, WET, CRYSTAL, CALCIUM Batteries Type Selections
  • Targeted for Lithium Batteries: LiFePO4, LTO (Lithium Titanate Oxide), LCO Batteries Type Selections



Specifications

  • System Nominal Voltage: 12/24V Auto
  • Max PV Open Circuit Voltage: 100V DC
  • Charging Technology: MPPT
  • Max PV Charging Current: 50A
  • Max. Recommended PV Input Power: 700 Watt (12V) / 1400 Watt (24V)
  • Charge Conversion Efficiency: ≤98%
  • MPPT Tracking Efficiency: >99.5%
  • Battery Type Preset: Crystal, Gel, AGM, WET, Calcium / LCO, LFP, LTO
  • Housing Case Color: Black / Grey
  • IP Grade: IP43 for Inside PCBA, IP22 for Connection Area
  • Net Weight: 1.40kg / 3.09lb
  • Dimensions (L*W*H): 195*140*74 mm / 7.7*5.5*2.9 in
